MOXA Layer 2 Managed Switches

Moxa's Layer 2 managed switches feature industrial-grade reliability, network redundancy, and security features based on the IEC 62443 standard. We offer toughened, industry-specific products with multiple industry certifications, such as parts of the EN 50155 standard for rail applications, IEC 61850-3 for power automation systems, and NEMA TS2 for intelligent transportation systems.

EDS-510E-3GTXSFP-T

EDS-510E Series

Managed Gigabit Ethernet switch with 7 10/100BaseT(X) ports, 3 10/100/1000BaseT(X) or 100/1000BaseSFP ports, -40 to 75°C operating temperature

EDS-510E Series

7+3G-port Gigabit managed Ethernet switches

Features and Benefits

•  3 Gigabit Ethernet ports for redundant ring or uplink solutions

•  Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250 switches),  RSTP/STP, and MSTP for network redundancy

•  RADIUS, TACACS+, SNMPv3, IEEE 802.1x, HTTPS, SSH, and sticky MAC address to enhance network security

•  Security features based on IEC 62443

•  EtherNet/IP, PROFINET, and Modbus TCP protocols supported for device management and monitoring

•  Supports MXstudio for easy, visualized industrial network management

•  V-ON™ ensures millisecond-level multicast data and video network recovery

Introduction

The EDS-510E Gigabit managed Ethernet switches are designed to meet rigorous mission-critical applications, such as factory automation, ITS, and process control. The 3 Gigabit Ethernet ports allow great flexibility to build up a Gigabit redundant Turbo Ring and a Gigabit uplink. The switches have USB interfaces for switch configuration, system file backup, and firmware upgrade, making them easier to manage.

Additional Features and Benefits

• Command line interface (CLI) for quickly configuring major managed functions

•


• DHCP Option 82 for IP address assignment with different policies

•


• Supports EtherNet/IP, PROFINET, and Modbus TCP protocols for device management and monitoring

•


• IGMP snooping and GMRP for filtering multicast traffic

•


• Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning

•


• Configurable by web browser, Telnet/USB console, CLI, MXconfig, and ABC-02-USB automatic backup configurator

•


• QoS (IEEE 802.1p/1Q and TOS/DiffServ) to increase determinism

•


• Port Trunking for optimum bandwidth utilization

•


• SNMPv1/v2c/v3 for different levels of network management

•


• RMON for proactive and efficient network monitoring

•


• Bandwidth management to prevent unpredictable network status

•


• Lock port function for blocking unauthorized access based on MAC address

•


• Automatic warning by exception through email and relay output

Ordering Information

EDS-510E-3GTXSFP

EDS-510E-3GTXSFP-T

Accessories (sold separately)

Storage Kits

ABC-02-USB

ABC-02-USB-T

SFP Modules

SFP-1FELLC-T

SFP-1FEMLC-T

SFP-1FESLC-T

SFP-1G10ALC

SFP-1G10ALC-T

SFP-1G10BLC

SFP-1G10BLC-T

SFP-1G20ALC

SFP-1G20ALC-T

SFP-1G20BLC

SFP-1G20BLC-T

SFP-1G40ALC

SFP-1G40ALC-T

SFP-1G40BLC

SFP-1G40BLC-T

SFP-1GEZXLC

SFP-1GEZXLC-120

SFP-1GLHLC

SFP-1GLHLC-T

SFP-1GLHXLC

SFP-1GLHXLC-T

SFP-1GLSXLC

SFP-1GLSXLC-T

SFP-1GLXLC

SFP-1GLXLC-T

SFP-1GSXLC

SFP-1GSXLC-T

SFP-1GZXLC

SFP-1GZXLC-T

Power Supplies

DR-120-24

DR-4524

DR-75-24

MDR-40-24

MDR-60-24
