New Arrival Siemens 7MF4433-1GA02-2AB1 Transmitter HART, 4-20 mA for Differential Pressure and Flow
September
10, 2021
7MF4433-1GA02-2AB1-Z
SITRANS P DS III / P410, HART, 4-20 mA transmitter for differential pressure and flow PN 32/160 gas 1/liquids 1 art. 3.3 sep Measuring cell filling silicone normal cleaning Span: PN 160 (MWP 2320 psi): 50 to 5000 mbar (20.08 to 2008 inH2O), max. static pressure 160 bar Diaphragm stainless steel parts of measuring cell stainless steel Process connection: 1/4-18 npt mounting thread: M10 Die-cast aluminium housing, process flange bolts stainless steel International design english inscription documentation as cd None explosion protection Electric connection and cable inlet: cable gland M20 x1.5 without visible digital indicator (digital display hidden, setting: mA) With stainless steel mounting bracket
| Product | |
| Article Number (Market Facing Number) | 7MF4433-1GA02-2AB1-Z A02 |
| Product Description | SITRANS P DS III / P410, HART, 4-20 mA transmitter for differential pressure and flow PN 32/160 gas 1/liquids 1 art. 3.3 sep Measuring cell filling silicone normal cleaning Span: PN 160 (MWP 2320 psi): 50 to 5000 mbar (20.08 to 2008 inH2O), max. static pressure 160 bar Diaphragm stainless steel parts of measuring cell stainless steel Process connection: 1/4-18 npt mounting thread: M10 Die-cast aluminium housing, process flange bolts stainless steel International design english inscription documentation as cd None explosion protection Electric connection and cable inlet: cable gland M20 x1.5 without visible digital indicator (digital display hidden, setting: mA) With stainless steel mounting bracket |
| Product family | Not available |
| Product Lifecycle (PLM) | PM400:Phase Out Started |
| PLM Effective Date | Product phase-out since: 01/02/19 |
| Notes | Sucessor:Substitute: 7MF03..-.....-.... |
| Price data | |
| Price Group / Headquarter Price Group | 8P1 |
| List Price | |
| Customer Price | |
| Metal Factor | None |
| Delivery information | |
| Export Control Regulations | ECCN : N / AL : N |
| Standard lead time ex-works | 10 Day/Days |
| Net Weight (kg) | 4.500 Kg |
| Package size unit of measure | Not available |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | Not available |
| LKZ_FDB/ CatalogID | FI01-1 |
| Product Group | 4770 |
| Group Code | R3P0 |
| Country of origin | France |
| Compliance with the substance restrictions according to RoHS directive | Since: 20/07/17 |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
Model number for example:
7MF4433-1CA22-2AC6-Z A01
7MF44331EA021BB1
7MF44331CA021BB1
7MF4433-1CA02-1DB1
7MF4433-1GA02-1DB1
7MF4433-1CA22-2AC6-Z+A40+Y01
7MF4433-1FA22-2AC6-Z+Y01
7MF4433-1EA22-2AC6-Z+Y01
7MF4433-1DA22-2DC6-Z+A40+E56+Y01
7MF4433-1BA22-2DC6-Z+A40+E56+Y01
7MF4433-1BA22-2AC6-Z+A40+Y01
7MF4433-1DA22-2DC6-Z+E56+Y01
7MF4433-1EA62-1PC7-Z-B21-A02-H02-Y21
7MF4433-1HA22-1AB7-Z,Y02+Y15+Y21+C11+C12
7MF4433-1FA22-2AB7-ZA02
7MF4433-1EA22-1AB0
7MF4433-1EA02-2AB6-Z A01+Y01+Y15
7MF4433-1EA22-1AB0
7MF4433-1CA22-2AC6-Z+A40+Y01
7MF4433-1DA22-2DC6-Z+A40+E56+Y01
7MF4433-1DA22-2DC6-Z+E56+Y01
7MF4433-1FA22-2AC6-Z+Y01
7MF4433-3DA22-1AB0
7MF4433-1GA02-2AB1
7MF4433-1EA22-2AC6-Z, A02+A40+Y01+Y15
7MF4433-1GA22-1AB7
7MF4433-1DA02-2AB1-Z
7MF4433-1EA02-2BB7-Z+A02+C11+Y15+Y02+Y22
7MF4433-1FA03-1SC6-Z+A02+A20+A40+U02
7MF4433-1DA02-2AC6-Z,A01+Y01+Y15,SLNO.YSN/F3189185842
7MF4433-1CA02-2AC6-Z,A01+Y01+Y15,YSN/F318-9185832
7MF4433-1CA02-2AC6-Z,A01+Y01,YSNF9259201422
7MF4433-1FA22-1BB6-Z+C11+C12+D12+Y01+Y21
7MF4433-3EA22-1AB0
7MF4433-1DA22-1AB0
7MF4433-1DA02-1AB6
7MF4433-1DY22-1AB6-Z A02+B11+C14 + 7MF4923-1RA03-5B-Z C11+C12+V03
7MF4433-1FY02-2BC6-Z A02+Y01+Y1
-----------------------
